HXGN17-12 BOX TYPE FIXED METALENCLOSED SWITCHGEAR

HXGN17-12 box type fixed metal enclosed switchgear (referred to as ring network cabinet) is an AC high-voltage complete equipment device with a rated voltage of 12kV and a rated frequency of 50Hz. It is mainly used for alternating current ring networks, terminal distribution networks, and industrial electrical equipment, as well as for receiving, distributing electrical energy, and protecting. It is also suitable for installation in box-type substations.

Comply with GB3906 "3.6-40.5 AC Metal Enclosed Switchgear and Control Equipment" and comply with the requirements of international standard IEC298 "AC Metal Enclosed Switchgear and Control Equipment". And it has the "five prevention" interlocking function.

Surrounding air temperature: -15 ℃~+40 ℃

Altitude: 1000m and below

Earthquake intensity: not exceeding 8 degrees;

Places without obvious pollution such as corrosive or combustible gases.

Humidity conditions: The daily average value shall not exceed 95%, and the daily average value of water vapor pressure shall not exceed 2.2kPa; The monthly average value shall not exceed 90%, and the monthly average value of water vapor pressure shall not exceed 1.8kPa

Note: When the above normal usage conditions are exceeded, users can negotiate with our company.
