Transformer Pressure Vacuum Gauge

The vacuum pressure gauge is a pressure measuring instrument specially designed for box-type power transformers.

The measuring range is -10~10PSIG.

Parameters

• Material:
• Case: 304 stainless steel, polish, non-vent
• Pointer: Aluminium, white painting, non-adjustable
• Lens: Polymethyl methacrylate
• Accuracy: 3%
• Connection: Brass 1/4 NPT-18
• Pressure spring tube: Phosphor copper
