35kV 600/900A Deadbreak Apparatus Bushing

The 35kV deadbreak apparatus bushing is epoxy molded, meeting the full requirements of IEEE Std 386™-2016 standard separable insulated connector systems. All 600A/900A separable connectors manufactured according to IEEE Std 386™-2016 standard will operate with this bushing.

The bushing is designed for sidewall mounting in transformers, switches, and other apparatus filled with transformer oil or an approved equivalent. Separable connector systems, such as T-body and Elbow deadbreak connectors, as well as other similar systems on the market, can be used with this bushing.
